Complete Oil Pan Swap Kit for LS1 Camaro / Firebird (F-Body)

Complete Oil Pan Swap Kit for LS1 Camaro / Firebird (F-Body)
Click to enlarge
Price $329.99
Model DD-LS-OP-CAM
Manufacturer Dirty Dingo
Quantity:
  Add to Wish List

Description

The F-Body oil pan is the pan of choice for most engine swaps as it provides the most steering rack clearance of any GM pan as well as generous ground clearance. Using a factory GM pan allows you to retain the structural rigidity of a cast aluminum pan.

Includes

  • GM Part # 12628771 - GM LS1 F-Body oil pan, gasket, stock baffle, drain plug and mounting hardware
  • GM Part # 12551581 - GM LS1 F-Body oil dip stick
  • GM Part # 12551577 - GM LS1 F-Body oil dip stick tube
  • GM Part # 12558251 - GM LS1 F-Body oil pickup tube
  • GM Part # 12558253 - GM LS1 F-Body windage tray

Applications

  • 1998-2002 Pontiac Firebird Formula and Trans Am
  • 1998-2002 Chevrolet Camaro Z28 and SS
  • Bolts to all GM Gen III & IV LS family engines including LS1, LS6, LS2, LS3, LS7, LS9, L76, L98, L92, L93, L99, LQ4, LQ9, LSA, LSX and V8 Vortec variations
  • Delco PF63 Wix 57045 taller filter (4.828") for the newer 22mm threads.
    Delco PF48 Wix 57060 shorter filter (3.45") for 22mm threads



Images

Complete Oil Pan Swap Kit for LS1 Camaro / Firebird (F-Body)
Click to enlarge
Complete Oil Pan Swap Kit for LS1 Camaro / Firebird (F-Body)
Click to enlarge

Mfg Info

Manufacturer Info
Other products

Extra Info

Comments
There are currently no product reviews
Write a review on this product!
