Dirty Dingo Universal Adjustable LS Engine Mounts
Dirty Dingo’s patented universal engine mounts are designed to install a 1997–2013 GM Gen III or Gen IV LS engine into many street rod, hot rod, and custom frame setups.
The mounts are precision CNC laser-cut and CNC-formed from strong 1/4-inch cold-rolled steel. Their slotted design allows up to 3 inches of front-to-back engine adjustment. This makes it easier to place the engine where it fits best.
Many engine mounts hold the engine in only one position. This can create extra work if you change transmissions later. You may need to rebuild or move the transmission crossmember. Dirty Dingo mounts let you move the engine forward or rearward, giving you more options for the engine and transmission setup.
The mounts are available by themselves or as a complete package. The complete package includes Hyper-Flex polyurethane isolators to help control vibration.
Both the engine-side and frame-side mounts have adjustable holes. The frame-side mounts can be trimmed up to 1 inch on each side. This allows the mounts to fit chassis with an inside frame width from 19.125 to 26.75 inches.
Important Information
-
Made from 1/4-inch cold-rolled steel.
-
Sold as raw, unpainted steel.
-
Black textured powder coating is available.
-
Sold as a left and right pair.
-
Grade 8 zinc-coated hardware is included.
-
Mounts are welded and cooled in a fixture to keep them properly aligned.
-
These mounts will not fit Dart aftermarket engine blocks.
-
These mounts will not clear a low-mounted A/C compressor.
-
They will clear a low-mounted alternator, but engine adjustment may be limited.
Additional Vehicle Applications
These universal mounts can also be welded into the following vehicles:
-
1981–1985 Jeep CJ10
-
1972–1986 Jeep CJ5
-
1972–1975 Jeep CJ6
-
1976–1986 Jeep CJ7
-
1981–1986 Jeep CJ8
-
1972–1984 Jeep Grand Wagoneer
-
1981–1985 Jeep J-Series Truck
-
1972–1984 Jeep SJ Cherokee
-
1972–1984 Jeep Wagoneer
-
1946–1965 Jeep Willys Wagon
-
1987–1995 Jeep YJ
-
1963–1984 Toyota Land Cruiser FJ40
-
1967–1980 Toyota Land Cruiser FJ55
-
1981–1987 Toyota Land Cruiser FJ60
-
1988–1990 Toyota Land Cruiser FJ62
|
