LS Street Rod A/C Kit with Sanden Mini Compressor and Billet Adapter
This item is oversized. Additional shipping charges apply.
This Dirty Dingo kit mounts a Sanden SD7B10 7176 mini A/C compressor in front of the passenger-side cylinder head. It fits Gen 3 and Gen 4 LS engines with Vortec truck, 2010–2015 Camaro, or VVT accessory spacing.
Designed for narrow street rod engine bays, the kit keeps the compressor close to the block, below the top of an LS1 car-style intake manifold, and no wider than the exhaust at the cylinder head.
The brackets are precision CNC machined from 1½-inch-thick 6061-T6 aircraft-grade billet aluminum.
Kit Includes:
-
Billet aluminum A/C brackets
-
Compact, high-strength flat-spring belt tensioner
-
All required Grade 8 zinc-coated mounting hardware
-
New Sanden SD7B10 7176 mini compressor with a 6-groove serpentine clutch
-
CNC-machined 6061-T6 billet aluminum O-ring adapter
Compressor and Fitting Details:
-
Designed for R-134a refrigerant
-
Supplied with PAG oil; check the oil type and amount before installation
-
Displacement: 100 cc / 6.10 cubic inches
-
Adapter converts the compressor’s flange ports to O-ring-style connections
-
Discharge fitting: Male #8, ¾"-16
-
Suction fitting: Male #10, ?"-14
Serpentine belt not included. Check the installation instructions for the suggested belt size for your setup.
View Installation Instructions
Compressor Warranty and Installation Requirements
Compressors include a one-year manufacturer warranty. Warranty returns must be sent to the manufacturer for testing, which may take several weeks. The manufacturer will check whether the compressor was installed and oiled correctly. The customer is responsible for all shipping costs.
A failed compressor can spread debris through the A/C system. When installing a replacement compressor:
-
Perform a full system flush.
-
Replace the orifice tube or expansion valve and the drier or accumulator.
-
Replace any other damaged or contaminated parts.
-
Replace the condenser when required for the compressor application.
Warranty coverage requires correct installation and proof of installation, including replacement of the drier and metering device.
The customer must check the required oil type and amount. We strongly recommend draining the supplied oil and adding the correct PAG oil type and amount for the application.
Oil Requirements:
Follow all local, state, and federal rules when servicing vehicle A/C systems.
|
